Skylight profiles are a product line designed specifically for BP2 trapezoidal sheets. Each model addresses different needs – from lightweight and economical solutions to strong and durable rooflights intended for industrial facilities. Thanks to them, the interiors of halls, utility rooms, or commercial buildings gain access to natural daylight, improving comfort, reducing energy consumption, and enhancing the overall aesthetics of the investment.
The SKY-T18 skylight is a dedicated solution for T-18 trapezoidal sheets, combining high daylight transmission with a durable structure. It provides effective illumination for halls and smaller rooms. It is highly impact-resistant while maintaining the aesthetics and functionality of the structure.
Technical parameters
Thickness:
1.0 mm
Effective width:
1063±5 mm
Sheet width:
1117±5 mm
Wave pitch:
134 mm
Wave height:
18 mm
Sheet length:
3 m
Color:
Clear
Structure:
Solid sheet
UV protection:
Yes
Fire classification:
B s1 d0
Operating temperature range:
-40° / +130°C
Linear thermal expansion:
6.7 × 10-5 mm/mm °C
Chemical resistance (use and maintenance):
Specification in literature
Thermal insulation:
5.70 W/mK
Light transmission (CLEAR):
89±2 %
Warranty:
10 years*
Application: implementation of skylights and flat roof coverings
Accessories: the system is complemented by accessories (for detailed information about accessories, please contact the manufacturer).
NOTE: to achieve skylights with high insulation parameters in accordance with the applicable standard, an internal suspended ceiling may be added.
SKY-T18 ECO Skylight
The SKY-T18 ECO is a lightweight and economical skylight designed specifically for T18 ECO trapezoidal sheet. It is an effective alternative to artificial lighting, offering high transparency and durability while maintaining energy-saving parameters – ideal for agricultural and investment facilities.
Technical parameters
Thickness:
1.0 mm
Effective width:
1170±5 mm
Sheet width:
1120±5 mm
Wave pitch:
187.5 mm
Wave height:
16.5 mm
Sheet length:
3 m
Color:
Clear
Structure:
Solid sheet
UV protection:
Yes
Fire classification:
B s1 d0
Operating temperature range:
-40° / +130°C
Linear thermal expansion:
6.7 × 10-5 mm/mm °C
Chemical resistance (use and maintenance):
Specification in literature
Thermal insulation:
5.70 W/mK
Light transmission (CLEAR):
89±2 %
Warranty:
10 years*
Application: implementation of skylights and flat roof coverings
Accessories: the system is complemented by accessories (for detailed information about accessories, please contact the manufacturer).
NOTE: to achieve skylights with high insulation parameters in accordance with the applicable standard, an internal suspended ceiling may be added.
SKY-T35 Skylight
The SKY-T35 is a strong and durable skylight dedicated to T35 trapezoidal sheets, designed for facilities requiring a robust structure. It guarantees effective interior illumination, high weather resistance, and maintains the aesthetic appearance of roofs in industrial and commercial buildings.
Technical parameters
Thickness:
1.0 mm
Effective width:
1065 ± 5 mm
Sheet width:
1119 ± 5 mm
Wave pitch:
213 mm
Wave height:
34 mm
Sheet length:
3 m
Color:
Clearal
Structure:
Solid sheet
UV protection:
Yes
Fire classification:
B s1 d0
Operating temperature range:
-40° / +130°C
Linear thermal expansion:
6.7 × 10-5 mm/mm °C
Chemical resistance (use and maintenance):
Specification in literature
Thermal insulation:
5.70 W/mk
Light transmission (CLEAR):
89 ± 2 %
Warranty:
10 years*
Application: implementation of accessories for skylights and flat roofs.
Accessories: the system is complemented by accessories (for detailed information about accessories, please contact the manufacturer).
NOTE: to achieve skylights with high insulation parameters in accordance with the applicable standard, an internal suspended ceiling may be added.
